Weight: 1.27 kg (2.81 lbs)

Weight Capacity: 9.1 kg (20 lbs)*

*Optimized for pro setups, up to full-frame DSLR + telephoto lens

*Carbon model has 20% improved stiffness. In most conditions, the difference will not be noticeable. With heavy gear in windy conditions, the Carbon model may let you take slightly sharper images.

Collapsed Dimensions:

Length: 39.1 cm (15.4”)

Diameter: 7.9 cm (3.125")

Deployed Dimensions:

Max height (center column raised): 152.4 cm (60")

Max height (center column down): 130.2 cm (51.25")

Min height (low mode): 14 cm (5.5”)

Tabletop Mode (center column raised): 57.2 cm (22.5")

Tabletop Mode (center column down): 35.9 cm (13.125")

Leg sections: 5

Leg locks: aluminum cams

Materials:

Ball head, hub, load hook: Powder Coated A380 aluminum

Legs, center column: Carbon F’n fiber (Carbon)

Quick release, adjustment ring, center column knob: Anodized 6061-T6 aluminum

Locking ring: Polycarbonate/ABS blend

Feet: Shore A60 TPU

Sub-Assembly Weights

Carbon Legs: 1.3 kg (2.87 lbs)

Carbon Center Column: 0.05 kg (0.11 lbs)

Aluminum Legs: 1.0 kg (2.2 lbs)

Aluminum Center Column: 0.034 kg (0.075 lbs)

Ball Head: 0.2 kg (.44 lbs)

Load Hook: 0.009 kg (0.02 lbs)

Mobile Mount: 0.01 kg (.03 lbs)

• tripod (legs + ball head)

• soft case

• standard plate

• mobile mount

• load hook

• 4mm + 2.5mm hex wrench

• bushing removal tool
